Export trace as JSON

Every trace can be downloaded as a self-contained JSON file from the trace detail page or from the CLI. The export captures trace metadata, every span (with input / output / attributes / events / model / tokens / cost), checkpoints (when the trace was durable), and attachment metadata. Image and PDF bytes are referenced by default — opt in to embedding them inline via a checkbox.

From the UI

Click Export on any trace detail page (top-right action bar). The dialog gives two opt-in toggles:

• Include image / PDF data — base64-embeds attachment bytes in the JSON. Default off; files can balloon to many MB.
• Include checkpoint state — embeds the full state_snapshot / node_input / node_output for every checkpoint. Default off; state snapshots are typically large.

Clicking Download navigates to the export endpoint with the chosen flags as query params; the browser handles the file save via the Content-Disposition header.

From the CLI

fastaiagent export-trace reads the local SQLite DB directly — no running UI server required.

fastaiagent export-trace \
    --trace-id 3ea7986578bc6e2da8dcca18f5fddb8b \
    --output trace.json

# Embed image bytes too:
fastaiagent export-trace \
    --trace-id 3ea7986578bc6e2da8dcca18f5fddb8b \
    --output trace-full.json \
    --include-attachments \
    --include-checkpoint-state

The CLI accepts --db <path> to override the default local.db location. By default it resolves the same DB the UI server uses.

Endpoint

GET /api/traces/{trace_id}/export?include_attachments=false&include_checkpoint_state=false

The response carries a Content-Disposition: attachment; filename="trace-{id}.json" header so the browser saves it directly. The server caps the response at 100 MB and returns 413 Payload Too Large if the export would exceed that — re-run without include_attachments=true or use the CLI to filter.

Schema

{
  "export_version": "1.0",
  "exported_at": "2026-04-29T14:30:00+00:00",
  "sdk_version": "1.2.0",
  "trace": {
    "trace_id": "3ea7986578bc6e2da8dcca18f5fddb8b",
    "name": "agent.weather-bot",
    "status": "OK",
    "started_at": "2026-04-29T14:25:00+00:00",
    "duration_ms": 2460,
    "total_tokens": 312,
    "total_cost": 0.0004,
    "workflow_type": "agent",
    "runner": "weather-bot",
    "execution_id": "exec-abc",
    "durable": true
  },
  "spans": [
    {
      "span_id": "5538f703...",
      "name": "llm.openai.gpt-4o-mini",
      "parent_span_id": null,
      "status": "OK",
      "started_at": "...",
      "duration_ms": 2400,
      "input": {"gen_ai.request.messages": [{"role": "user", "content": "..."}]},
      "output": {"gen_ai.response.content": "..."},
      "attributes": {"...": "..."},
      "events": [],
      "model": "gpt-4o-mini",
      "tokens": {"input": 180, "output": 132},
      "cost": 0.0004
    }
  ],
  "checkpoints": [
    {"checkpoint_id": "...", "node_id": "research", "step": 0, "status": "completed", "...": "..."}
  ],
  "multimodal_attachments": [
    {
      "attachment_id": "...",
      "span_id": "...",
      "media_type": "image/jpeg",
      "size_bytes": 145000,
      "metadata": {"width": 320, "height": 200},
      "included": false,
      "note": "Attachment data excluded from export. Use include_attachments=True to embed base64 bytes."
    }
  ]
}

When include_attachments=true each attachment row also carries attachment_data (base64-encoded bytes); when include_checkpoint_state=true each checkpoint row also carries state_snapshot, node_input, node_output, and interrupt_context.

Single source of truth

Both the HTTP endpoint and the CLI command are thin wrappers around fastaiagent.trace.trace_export.build_export_payload, so the JSON shape stays identical regardless of which entrypoint produced it. Your scripts can call this helper directly:

from fastaiagent._internal.storage import SQLiteHelper
from fastaiagent.trace.trace_export import build_export_payload

with SQLiteHelper(".fastaiagent/local.db") as db:
    payload = build_export_payload(
        db,
        trace_id="3ea7986578bc6e2da8dcca18f5fddb8b",
        include_attachments=True,
    )

Try it from the examples

examples/48_export_trace.py runs a small Agent and writes its trace to trace.json using the same export_trace_to_file helper. After running, inspect the JSON to see the schema in action.

Where the screenshot comes from

The dialog screenshot is captured by scripts/capture-sprint1-screenshots.sh against the multimodal trace seeded by scripts/seed_ui_sprint1.py. The trace ID embedded in the download URL matches the one that page is showing.
